Name: DFRobot Gravity Color Temperature and Ambient Light Sensor - DFROBOT-SEN0611
Brand: DFRobot
SKU: 006669
Price: 30 EUR
Availability: InStock

DFRobot Gravity Color Temperature and Ambient Light Sensor

Availability: Directly available from warehouse in Eindhoven
SKU: 006669

Based on 0 review(s) - Write a review

€30.00

Ex Tax: €24.79

Qty

Add to Cart

Add to wishlist

Only 8 pieces in stock

Description
Reviews

This Gravity Color Temperature and Ambient Light Sensor from DFRobot offers both color temperature and light intensity detection. The module has a built-in sensor that measures the color temperature and brightness of ambient light. These values are easy to read via I2C or UART (selectable via a switch).

See the following page for more information: GitHub

See the following page for more information: Wiki

Please login or register to review

Reviews Over DFRobot Gravity Color Temperature and Ambient Light Sensor

Average Rating:

This product has 0 review(s) in total.

Tags: DFRobot Gravity Color Temperature and Ambient Light Sensor , DFROBOT-SEN0611 , Light and Color

Specifications

General
Brand	DFRobot
Manufacturer model/SKU	SEN0611
Minimum operating temperature [°C]	-10
Maximum operating temperature [°C]	60
Features	Light sensor
General physical appearance
Main color	Black
Weight [g]	3
Dimension X [mm]	26
Dimension Y [mm]	24
Mounting options	Mounting hole(s)
Diameter mounting hole(s) [mm]	3.1
Form factor	Module (general)
General electrical properties
Minimum supply voltage [V DC]	3.3
Maximum supply voltage [V DC]	5
Minimum IO-pin input voltage [V]	3.3
Maximum IO-pin input voltage [V]	5
IO-pin output voltage [V]	Equal to supply voltage
Communication
Hardware interface(s)	I2C UART
Default baudrate	9600
Default I2C address	0x32
Adjustable I2C address	No
Built-in pull-up resistor(s) [kΩ]	10
Light sensor
Sensor (chip)	TCS34303
Measurable light	Visible
Light sensor type	Light intensity Color temperature
Minimum measuring range [lux]	10
Maximum measuring range [lux]	10000
Accuracy [±lux]	5
Accuracy [±% lux]	10
Minimum measuring range [K]	2700
Maximum measuring range [K]	6500
Accuracy [±% K]	10
Connectors
Power supply connector(s)	JST-PH (compatible) male
IO-connector(s)	JST-PH (compatible) male
Package contents
Package contents	1x Color Temperature and Ambient Light Sensor 1x JST-PH female to DuPont female compatible cable
