Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°

Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110°
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 007521
Based on 0 review(s) - Write a review
€24.50
Ex Tax: €20.25
Add to Cart
Add to wishlist

A camera module with a wide lens from Waveshare. The module is compatible with all Raspberry Pi boards.

See the following page for more information: Wiki

Please login or register to review
Tags: Optical , Cameras and Scanners , Waveshare OV9281 Monochrome Global Shutter Camera Module for Raspberry Pi - CSI - 1MP - 110° , 007521 , Waveshare , 21653 , Camera , MIPI (CSI)

Specifications

General
Brand Waveshare
Manufacturer model/SKU 21653
Features Camera
General physical appearance
Main color Black
Weight [g] 6
Dimension X [mm] 25
Dimension Y [mm] 24
Mounting options Mounting hole(s)
Diameter mounting hole(s) [mm] 2.2
Form factor Module (general)
Communication
Hardware interface(s) MIPI (CSI)
Scanner/camera
Type Camera
Sensor(chip) OV9281
Lense type Wide
Number of pixels long side 1296
Number of pixels short side 816
Maximum frame rate [Hz] 210
(640x400)
180
(680x480 (VGA))
130
(1280x720 (720p))
120
(1280x800)
Pixel colors Monochrome (black-white)
Focal length [mm] 2.1
Aperture 2.2
Global/rolling shutter Global
Maximum viewing angle (diagonal) [°] 110
Connectors
Power supply connector(s) FFC female 15p 1.00mm
IO-connector(s) FFC female 15p 1.00mm
Wire/cable
Wire/cable length [m] 0.15
Package contents
Package contents 1x Camera module
1x FFC flex cable 15p
1x FPC-FFC flex cable 22p to 15p
