Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°

Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
2-4 Weeks
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°
  • Availability: 2-4 Weeks
  • SKU: 005888
Based on 0 review(s) - Write a review
€17.00
Ex Tax: €14.05
Add to Cart
Add to wishlist

This camera can be used to replace the standard camera on the Raspberry Pi Camera V2 module. The module is compatible with all Raspberry Pi boards.

Note: The included cable is only suitable for use with the Raspberry Pi 5 and Rasperry Pi Zero.

See the following page for more information: Wiki

Please login or register to review

Reviews Over Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120°

This product has 0 review(s) in total.

Tags: Optical , Cameras and Scanners , Waveshare IMX219 Camera Module for Raspberry Pi 5 - 8MP - 120° , 005888 , Waveshare , 26185 , Camera , MIPI (CSI)

Specifications

General
Brand Waveshare
Manufacturer model/SKU 26185
Features Camera
General physical appearance
Main color Black
Weight [g] 3
Dimension X [mm] 25
Dimension Y [mm] 24
Dimension Z [mm] 6
Mounting options Mounting hole(s)
Diameter mounting hole(s) [mm] 2.2
Form factor Module (general)
Communication
Hardware interface(s) MIPI (CSI)
Scanner/camera
Type Camera
Sensor(chip) IMX219
Lense type Wide
Number of pixels long side 3280
Number of pixels short side 2464
Focal length [mm] 1.79
Aperture 2.00
Maximum viewing angle (diagonal) [°] 120
Connectors
Power supply connector(s) FFC female 15p 1.00mm
IO-connector(s) FFC female 15p 1.00mm
Wire/cable
Shielding Yes
Wire/cable length [m] 0.2
Package contents
Package contents 1x Pi5-IMX219-120
1x Raspberry Pi 5 camera cable - 22 to 15 pin FPC-FFC flex - 20cm
