Radxa Camera 8M 219 - IMX219

Based on 0 review(s) - Write a review

€17.50

Ex Tax: €14.46

Qty

Add to Cart

Add to wishlist

Only 4 pieces in stock

A camera module from Radxa.

Note: The Radxa ROCK 5 series requires the following adapter cable: Radxa Camera FPC Cable for ROCK 5

See the following page for more information: Wiki

See the following page for more information: Manufacturer page

Please login or register to review

This product has 0 review(s) in total.

Tags: Radxa Camera 8M 219 - IMX219 , AS003 , Cameras and Scanners

General
Brand	Radxa
Manufacturer model/SKU	AS003
Features	Camera
General physical appearance
Main color	Green
Weight [g]	8
Dimension X [mm]	32
Dimension Y [mm]	32
Mounting options	Mounting hole(s)
Diameter mounting hole(s) [mm]	2
Form factor	Module (general)
Communication
Hardware interface(s)	CSI
Scanner/camera
Type	Camera
Sensor(chip)	IMX219
Lense type	Normal
Number of pixels long side	3280
Number of pixels short side	2464
Maximum frame rate [Hz]	30
Focal length [mm]	2.95
Maximum viewing angle (diagonal) [°]	54
Connectors
Power supply connector(s)	FFC female 15p 1.00mm
IO-connector(s)	FFC female 15p 1.00mm
Package contents
Package contents	1x Camera module 1x FFC cable 15p 1.00mm 150mm (for Radxa ROCK 3/4) 1x FFC cable 15p 1.00mm to 22p 0.50mm (for Radxa ZERO 3W / 3E)
