DC-DC Step-down Buck Converter 4A - 11-32V to 9V output

Based on 0 review(s) - Write a review

€3.00

Ex Tax: €2.48

Qty

Add to Cart

Add to wishlist

100+ pieces in stock

A small step-down buck converter.

Please login or register to review

This product has 0 review(s) in total.

Tags: DC-DC Step-down Buck Converter 4A - 11-32V to 9V output , MINI560-PRO-9V , Buck (Step-Down) Converters

General
Brand	No brand
Manufacturer model/SKU	MINI 560 PRO 9V
Minimum operating temperature [°C]	-40
Maximum operating temperature [°C]	85
Features	Voltage converter
General physical appearance
Main color	Blue
Weight [g]	5
Dimension X [mm]	33
Dimension Y [mm]	18
Mounting options	SMT
Form factor	Module (general)
Voltage converter
Voltage converter type	Buck
Conversion	DC-DC
Switching method	Non-synchronous
Isolated	No
Output voltage type	Fixed
Constant current function	No
Maximum switching frequency [kHz]	500
Minimum input voltage [V DC]	11
Maximum input voltage [V DC]	32
Minimum output voltage [V DC]	9
Maximum output voltage [V DC]	9
Minimum input and output voltage difference [V DC]	2
Maximum output current [A]	4.0 (With cooling) 2.5 (without cooling)
Maximum output power [W]	36
Safety features	Short circuit Overcurrent (output) Temperature
Connectors
Input voltage connector(s)	Through hole solder pin(s) (2.54mm) Solder pin(s) (SMT)
Output voltage connector(s)	Through hole solder pin(s) (2.54mm) Solder pin(s) (SMT)
Package contents
Package contents	1x DC-DC buck converter
