Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector

Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector
Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector
Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector
Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector
Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 001784
Based on 0 review(s) - Write a review
€4.25
Ex Tax: €3.51
10 or more €4.00
20 or more €3.75
50 or more €3.50
100 or more €3.25
Add to Cart
Add to wishlist

This solar panel can be used to power your project with solar power.

Specifications:

  • Typical voltage: 5.5V
  • Typical current: 100mA
  • Open-circuit voltage: 8.2 V
  • Maximum load voltage: 6.4V
  • Dimensions: 70x55x3(±0.2) mm
  • Comes with ~15cm wires with JST-PH compatible connector(2.0mm pin pitch) presoldered
  • Type of solar cells: monocrystalline

The voltage from this solar panel is unregulated, so the 5V device must also be able to withstand a lower voltage. (able to withstands voltages between 0V and 5V)

Please login or register to review
Tags: Seeed Studio Solar Panel - 5.5V 100mA - 55x70mm - with JST-PH Compatible Connector , SEEED-313070004 , Solar Panels

Product FAQ

Why is the yield of the solar panel lower than expected?

The highest yield of a solar panel is only achievable under ideal conditions. This is when the sun shines perpendicular to the panel in the summer at the highest position of the sun when there are no clouds.
