Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White

Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White
Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White
Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White
Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White
Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 007336
Based on 0 review(s) - Write a review
€33.00
Ex Tax: €27.27
Add to Cart
Add to wishlist

With this Sonoff switch, lights in the home are smartly controlled via the Zigbee protocol.

See the following page for more information: Wiki

Check the tab "Downloads" for more information and/or downloads.

Please login or register to review

Reviews Over Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White

This product has 0 review(s) in total.

Tags: Sonoff , Zigbee , Sonoff ZBM5-2C-80W SwitchMan - Zigbee Switch - 2 Channels - White , 007336 , Sonoff , ZBM5-2C-80W , Electric switch , Enclosure , Zigbee

Specifications

General
Brand Sonoff
Manufacturer model/SKU ZBM5-2C-80W
Norm conformity CE
RoHS
Minimum operating humidity [%R.H.] 5
Maximum operating humidity [%R.H.] 95
Minimum operating temperature [°C] -10
Maximum operating temperature [°C] 40
Features Enclosure
Electric switch
General physical appearance
Main color White
Weight [g] 142
Dimension X [mm] 86
Dimension Y [mm] 71
Dimension Z [mm] 41
Mounting options Mounting hole(s)
Form factor Module (general)
General electrical properties
Minimum supply voltage [V AC] 100
Maximum supply voltage [V AC] 240
Wireless communication
Interface(s) Zigbee
Zigbee chip/SoC EFR32MG22
Zigbee frequency [GHz] 2.4
Zigbee device type(s) Router
(neutral connected)
End device
(neutral not connected)
Switch
Switching method Electrical
Switch type Mechanical relay
Number of channels/gangs 2
Contact(s) NO (normally open)
Maximum switching voltage [V AC] 240
Switching voltage equal to supply voltage Yes
Maximum switching current per channel (resistive load) [A] 10
(resistive)
1.67
(led)
Maximum switching current (channels combined) [A] 10
Connectors
Power supply connector(s) Screw terminal
Switch connector(s) Screw terminal
Zigbee/Thread antenna connector Built-in antenna
Enclosure
Material Steel
Polycarbonate (PC)
Package contents
Package contents 1x Sonoff switch
2x Mounting bolt
1x Quick start guide
