Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch

Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch
Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch
Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch
Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch
Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 007656
Based on 0 review(s) - Write a review
€33.25
Ex Tax: €27.48
Add to Cart
Add to wishlist

The Sonoff MINI-ZBDIM is an extremely Zigbee dimmer switch that fits into most EU type junction boxes. It can be controlled with Android or iOS with the eWeLink app. In addition, it is also compatible with Home Assistant.

Note: A Zigbee bridge is required, for example: Sonoff ZB Bridge-P (in combination with eWeLink) or Sonoff ZBDongle-E (in combination with, for example, Home Assistant).

See the following page for more information: Wiki

Check the tab "Downloads" for more information and/or downloads.

Please login or register to review

Reviews Over Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch

This product has 0 review(s) in total.

Tags: Sonoff , Zigbee , Sonoff MINI DIM - MINI-ZBDIM - Zigbee Dimmer Switch , 007656 , Sonoff , MINI-ZDIM , Electric switch , Enclosure , Zigbee

Specifications

General
Brand Sonoff
Manufacturer model/SKU MINI-ZDIM
Norm conformity CE
RoHS
Minimum operating humidity [%R.H.] 5
Maximum operating humidity [%R.H.] 95
Minimum operating temperature [°C] -10
Maximum operating temperature [°C] 40
Features Enclosure
Electric switch
General physical appearance
Main color White
Weight [g] 25
Dimension X [mm] 45
Dimension Y [mm] 40
Dimension Z [mm] 17
Form factor Module (general)
General electrical properties
Minimum supply voltage [V AC] 220
Maximum supply voltage [V AC] 240
Maximum power [W] 400
(Incandescent and halogen bulb)
200
(Dimmable electronic transformer)
200 VA
(Dimmable LED light)
Wireless communication
Interface(s) Zigbee
Zigbee frequency [GHz] 2.4
Zigbee device type(s) Router
Switch
Switching method Electrical
Switch type Dimmer (trailing-edge)
Number of channels/gangs 1
Contact(s) NO (normally open)
Maximum switching voltage [V AC] 240
Switching voltage equal to supply voltage Yes
Maximum switching current per channel (resistive load) [A] 1.6
(Incandescent and halogen bulb)
0.8
(LED and dimmable electronic transformer)
Connectors
Power supply connector(s) Screw terminal
IO-connector(s) Screw terminal
Switch connector(s) Screw terminal
Zigbee/Thread antenna connector Built-in antenna
Enclosure
Material Polycarbonate (PC) V0
Package contents
Package contents 1x MINI-ZBDIM
1x Quick start guide
