Sonoff RE5V1C - 5V Wi-Fi Relay Module - ESP8285

Availability: Directly available from warehouse in Eindhoven
SKU: 004684

Based on 0 review(s) - Write a review

€6.50

Ex Tax: €5.37

Qty

Add to Cart

Add to wishlist

20+ pieces in stock

Description
Reviews

This switch from Sonoff is a very handy Wi-Fi switch with timer for IoT applications with a low supply voltage. It can be controlled with Android or iOS with the eWeLink app. In addition, it is also compatible with other home automation platforms such as Amazon Alexa, Google Assistant, IFTTT and Google Nest.

Please login or register to review

Reviews Over Sonoff RE5V1C - 5V Wi-Fi Relay Module - ESP8285

Average Rating:

This product has 0 review(s) in total.

Tags: Sonoff RE5V1C - 5V Wi-Fi Relay Module - ESP8285 , SONOFF-RE5V1C , Wi-Fi

Specifications

General
Brand	Sonoff
Manufacturer model/SKU	RE5V1C
Model revision	V1.0
Minimum operating humidity [%R.H.]	5
Maximum operating humidity [%R.H.]	90
Minimum operating temperature [°C]	0
Maximum operating temperature [°C]	40
Features	Electric switch
General physical appearance
Main color	Green
Weight [g]	9
Dimension X [mm]	35
Dimension Y [mm]	26
Dimension Z [mm]	19
Mounting options	Mounting hole(s)
Diameter mounting hole(s) [mm]	2.5
Form factor	Module (general)
General electrical properties
Minimum supply voltage [V DC]	5
Maximum supply voltage [V DC]	5
MCU/SoC
Manufacturer	Espressif
Chip series	ESP8285
Maximum clock frequency [MHz]	160
Number of cores	1
Wireless communication
Interface(s)	Wi-Fi
Wi-Fi chip/SoC	ESP8285
Wi-Fi frequency [GHz]	2.4
Switch
Switching method	Electrical
Switch type	Mechanical relay
Number of channels/gangs	1
Contact(s)	NO (normally open)
Maximum switching voltage [V AC]	250
Maximum switching voltage [V DC]	30
Switching voltage equal to supply voltage	No
Maximum switching current per channel (resistive load) [A]	10
Connectors
Power supply connector(s)	Through hole solder pin(s)
Switch connector(s)	Through hole solder pin(s)
Pin distance [mm]	3.50 (Power supply connector)
Wi-Fi/Bluetooth antenna connector	Built-in antenna
Package contents
Package contents	1x Sonoff RE5V1C
