Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285

Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285
Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285
Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285
Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285
Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 003092
Based on 0 review(s) - Write a review
€26.00
Ex Tax: €21.49
10 or more €25.75
20 or more €25.50
50 or more €25.25
100 or more €25.00
Add to Cart
Add to wishlist

The Sonoff 4CH is a very handy 4-channel Wi-Fi switch with timer for IoT applications. It can be controlled with Android or iOS with the eWeLink app. This Wi-Fi switch is also compatible with Amazon Alexa, Google Assistant, IFTTT and Google Nest. This module also has the option to mount it on a DIN rail.

Specifications:

  • Voltage range: 90-250V AC (50/60Hz)
  • Max. current per channel: 10A
  • Max. current (total of channels): 16A
  • Max. switching power per channel: 2200W
  • Max. switching power (total of the channels): 3500W
  • Wi-Fi chip: ESP8266 or ESP8285 (new)
  • Dimensions: 145*90*34mm (l*w*h)
  • Wireless standard: 802.11 b/g/n
  • Security mechanism: WPA-PSK/WPA2-PSK
  • Working temperature: -10ºC-40ºC

See the following page to get started with the Sonoff 4CH: Sonoff 4CH User Guide

Please login or register to review

Reviews Over Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285

This product has 0 review(s) in total.

Tags: Sonoff 4CH R3 - Wi-Fi Switch - ESP8266/ESP8285 , SONOFF-4CHR3 , Wi-Fi

Product FAQ

My Sonoff device will not connect to the Wi-Fi network.

Some Sonoff devices have trouble connecting to a Wi-Fi network that runs on both 2.4GHz and 5GHz. However, there is a trick to work around this issue. The following steps can be followed for this:

  1. Create a mobile hotspot with a smartphone. Use exactly the same name and password as for the 2.4 GHz network of your modem/router.
  2. Turn off the modem/router completely.
  3. Pair the Sonoff device with the mobile hotspot of the smartphone set up in step 1.
  4. Turn off the mobile hotspot from step 1 after the Sonoff device is successfully paired.
  5. Turn the modem/router back on.

Additionally, some Sonoff Wi-Fi products require 802.11b support. Consult the manual of your router or access point to learn if 802.11b is supported and how to set it up.

If you have a question or problem regarding a product, please contact us by using one of the buttons below.

Product questions
Warranty and problems
Mistake on this product page
