RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red

RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red
RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red
RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red
RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red
RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 007534
Based on 0 review(s) - Write a review
€18.00
Ex Tax: €14.88
Add to Cart
Add to wishlist

The RAK14000 as an E-ink display module from RAKwireless for the modular WisBlock platform. The module comes with an 2.13 inch E-ink display and a membrane keypad with 3 buttons.

See the following page for more information: GitHub

See the following page for more information: Wiki

Please login or register to review
Tags: RAKwireless , Display and LED , RAKwireless RAK14000 2.3 inch E-Ink E-Paper Display Module - Black-White-Red , 007534 , RAKwireless , RAK14000/110024 , Display , Manual switch , SPI , Digital

Specifications

General
Brand RAKwireless
Manufacturer model/SKU RAK14000/110024
Features Display
Manual switch
General physical appearance
Main color Black
Weight [g] 3
(display)
2
(module)
1
(buttons)
Dimension X [mm] 60
(display)
25
(module)
49
(buttons)
Dimension Y [mm] 29
(display)
21
(module)
9.5
(buttons)
Mounting options Adhesive layer
Mounting hole(s)
Diameter mounting hole(s) [mm] 1.5
Form factor Module (general)
WisBlock IO Module
General electrical properties
Minimum supply voltage [V DC] 2.2
Maximum supply voltage [V DC] 3.7
Indication (deep-)sleep current [μA] 1
(deep-sleep mode)
20
(sleep mode)
Minimum IO-pin input voltage [V] 2.2
Maximum IO-pin input voltage [V] 3.7
IO-pin output voltage [V] Equal to supply voltage
Communication
Hardware interface(s) SPI
Digital
Display
Type E-paper
Driver SSD1680
Screen diagonal [inch] 2.13
Number of pixels long side 250
Number of pixels short side 122
Display shape Rectangular
Pixel colors Red
Black
White
Maximum refresh rate [Hz] 0.071
Switch
Switching method Physical (sensor switch)
Switch type Push
Number of channels/gangs 3
Connectors
Power supply connector(s) FBB04004 (WisBlock) 40p male
IO-connector(s) FFC female 6p 0.50mm
FFC female 24p 0.50mm
FBB04004 (WisBlock) 40p male
(module)
Package contents
Package contents 1x RAK14000 adapter module
1x E-ink display
1x Three button keypad
