0.91 inch OLED Display 128*32 pixels White - I2C

0.91 inch OLED Display 128*32 pixels White - I2C
0.91 inch OLED Display 128*32 pixels White - I2C
0.91 inch OLED Display 128*32 pixels White - I2C
0.91 inch OLED Display 128*32 pixels White - I2C
0.91 inch OLED Display 128*32 pixels White - I2C
0.91 inch OLED Display 128*32 pixels White - I2C
0.91 inch OLED Display 128*32 pixels White - I2C
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 001711
Based on 0 review(s) - Write a review
€4.00
Ex Tax: €3.31
10 or more €3.75
20 or more €3.60
50 or more €3.50
100 or more €3.40
200 or more €3.30
500 or more €3.20
1000 or more €3.10
Add to Cart
Add to wishlist

A 0.91 inch I2C OLED display with 128*32 white pixels and very good viewing angles of at least 160 degrees.

See the following page for a library for the Arduino IDE: Adafruit SSD1306

Check the tab "Downloads" for more information and/or downloads.

Please login or register to review

Reviews Over 0.91 inch OLED Display 128*32 pixels White - I2C

This product has 0 review(s) in total.

Tags: Displays , OLED , 0.91 inch OLED Display 128*32 pixels White - I2C , 001711 , ZHONGJINGYUAN , ZJY091I0400WG01 , Display , I2C

Specifications

General
Brand ZHONGJINGYUAN
Manufacturer model/SKU ZJY091I0400WG01
Features Display
General physical appearance
Main color Blue
Weight [g] 2
Dimension X [mm] 38
Dimension Y [mm] 12
Mounting options Pin headers
Form factor Module (general)
General electrical properties
Minimum supply voltage [V DC] 3.3
Maximum supply voltage [V DC] 5
Minimum IO-pin input voltage [V] 3.3
Maximum IO-pin input voltage [V] 3.3
IO-pin output voltage [V] 3.3
Communication
Hardware interface(s) I2C
Default I2C address 0x3C
Adjustable I2C address No
Built-in pull-up resistor(s) [kΩ] 4.7
Display
Type OLED
Driver SSD1306
Screen diagonal [inch] 0.91
Number of pixels long side 128
Number of pixels short side 32
Display shape Rectangular
Pixel colors White
Connectors
Power supply connector(s) Pin header male (2.54mm)
IO-connector(s) Pin header male (2.54mm)
Pinout
Power supply pin VCC
Ground/min GND
I2C SDA SDA
I2C SCL SCL
Package contents
Package contents 1x Display module
