Name: Waveshare 2.13 inch E-Ink E-Paper Display - for Raspberry Pi Pico - WS-19406
Brand: Waveshare
SKU: 006699
Price: 14.5 EUR
Availability: InStock

Waveshare 2.13 inch E-Ink E-Paper Display - for Raspberry Pi Pico

Availability: Directly available from warehouse in Eindhoven
SKU: 006699

Based on 0 review(s) - Write a review

€14.50

Ex Tax: €11.98

10 or more €14.25

20 or more €14.00

Qty

Add to Cart

Add to wishlist

50+ pieces in stock

Description
Reviews

A display module from Waveshare which can easily be placed as a shield on a Raspberry Pi Pico (or other microcontroller with the same pin layout).

See the following page for more information: Wiki

Please login or register to review

Reviews Over Waveshare 2.13 inch E-Ink E-Paper Display - for Raspberry Pi Pico

Average Rating:

This product has 0 review(s) in total.

Tags: Waveshare 2.13 inch E-Ink E-Paper Display - for Raspberry Pi Pico , WS-19406 , E-Ink

Specifications

General
Brand	Waveshare
Manufacturer model/SKU	19406
Features	Display
General physical appearance
Main color	Blue
Weight [g]	16
Dimension X [mm]	66
Dimension Y [mm]	31
Mounting options	Pin headers
Form factor	Module (general) Raspberry Pi Pico layout/shield
General electrical properties
Minimum supply voltage [V DC]	3.3
Maximum supply voltage [V DC]	5
Indication average current consumption [mA]	8
Indication (deep-)sleep current [μA]	0.01
Minimum IO-pin input voltage [V]	3.3
Maximum IO-pin input voltage [V]	3.3
IO-pin output voltage [V]	3.3
Communication
Hardware interface(s)	SPI
Display
Type	E-paper
Screen diagonal [inch]	2.13
Number of pixels long side	250
Number of pixels short side	122
Pixel colors	Black White
Maximum refresh rate [Hz]	0.5
Partial display refresh	Yes
Connectors
Power supply connector(s)	Pin header female (2.54mm)
IO-connector(s)	Pin header female (2.54mm)
Package contents
Package contents	1x Display module
