Name: LilyGO T-RSC3 - RS232 - RS485 - ESP32-C3 Development Board - LILYGO-H572
SKU: 005165
Price: 19.75 EUR
Availability: Discontinued

LilyGO T-RSC3 - RS232 - RS485 - ESP32-C3 Development Board

Discontinued

LilyGO T-RSC3 - RS232 - RS485 - ESP32-C3 Development Board

Availability: Discontinued
SKU: 005165

Based on 0 review(s) - Write a review

€19.75

Ex Tax: €16.32

Qty

Add to Cart

Add to wishlist

Not in stock

Description
Reviews

A development board based on an ESP32-C3 with various communication options.

See the following page for more information: GitHub

Please login or register to review

Reviews Over LilyGO T-RSC3 - RS232 - RS485 - ESP32-C3 Development Board

Average Rating:

This product has 0 review(s) in total.

Tags: LilyGO T-RSC3 - RS232 - RS485 - ESP32-C3 Development Board , LILYGO-H572 , With Bluetooth

Specifications

General
Brand	LilyGO TTGO
Manufacturer model/SKU	H572
Model revision	V1.1
Features	Microcontroller Programmable button(s) Digital LED(s)
General physical appearance
Main color	Black
Weight [g]	40
Dimension X [mm]	62
Dimension Y [mm]	56
Dimension Z [mm]	18
Mounting options	Mounting hole(s)
Diameter mounting hole(s) [mm]	2
Form factor	Module (general)
General electrical properties
Minimum supply voltage [V DC]	5
Maximum supply voltage [V DC]	24 (via screw terminal) 5 (via USB-C)
Minimum IO-pin input voltage [V]	3.3
Maximum IO-pin input voltage [V]	3.3
IO-pin output voltage [V]	3.3
Maximum IO-pin source current [mA]	40
Maximum IO-pin sink current [mA]	28
MCU/SoC
Manufacturer	Espressif
Chip series	ESP32-C3
Maximum clock frequency [MHz]	160
Number of cores	1
Internal memory
SRAM [KB]	400
PSRAM [MB]	0
Flash memory [MB]	4
EEPROM type	Emulated
Communication
Hardware interface(s)	I2C I2S SPI UART PWM GPIO RS485 RS232 USB CDC
Isolated communication	Yes (only RS232 and RS485)
Number of IO-pins	5
Maximum available hardware PWM channels	5
Maximum available analog input pins (ADC)	0
Maximum available analog output pins (DAC)	0
Maximum available hardware UART interfaces	2
Maximum available hardware I2C interfaces	1
Maximum available hardware SPI interfaces	1
USB to serial converter	Integrated into microcontroller
RS232 chip	RSM232MT5V
Number of RS232 channels	1
RS485 chip	RSM485MT5V
Number of RS485 channels	1
Wireless communication
Interface(s)	Wi-Fi Bluetooth
Wi-Fi chip/SoC	ESP32-C3
Wi-Fi frequency [GHz]	2.4
Bluetooth chip/SoC	ESP32-C3
Bluetooth version	5.0
Supported Bluetooth standard(s)	LE
LED
LED (driver) chip	WS2812C
LED color	RGB
Connectors
Power supply connector(s)	Screw terminal USB-C female
IO-connector(s)	Screw terminal Pin header female (2.54mm) USB-C female DB9 female
Wi-Fi/Bluetooth antenna connector	IPEX MHF 4 male
Package contents
Package contents	1x T-RSC3, 1x Wi-Fi/Bluetooth antenna with MHF 4 connector
