G-NiceRF LoRa-CC68-868 Module - 868MHz
- Availability: Directly available from warehouse in Eindhoven
- SKU: 004362
€6.00
Ex Tax: €4.96
Your shopping cart is empty!
A LoRa module from G-NiceRF.
See the following page for more information: Manufacturer page
Check the tab "Downloads" for more information and/or downloads.
General | |
Brand | G-NiceRF |
Manufacturer model/SKU | LoRa-CC68-868 |
Model revision | V2.0 |
Norm conformity | RoHS CE |
Minimum operating temperature [°C] | -40 |
Maximum operating temperature [°C] | 85 |
General physical appearance | |
Main color | Gray/silver |
Weight [g] | 1 |
Dimension X [mm] | 16 |
Dimension Y [mm] | 16 |
Dimension Z [mm] | 2.1 |
Mounting options | SMT |
Form factor | Individual component |
General electrical properties | |
Minimum supply voltage [V DC] | 1.8 |
Maximum supply voltage [V DC] | 3.7 |
Minimum IO-pin input voltage [V] | 1.8 |
Maximum IO-pin input voltage [V] | 3.7 |
IO-pin output voltage [V] | Equal to supply voltage |
Communication | |
Hardware interface(s) | SPI |
Wireless communication | |
Interface(s) | LoRa |
LoRa chip/SoC | LLCC68 |
LoRa frequency [MHz] | 868 |
Connectors | |
Power supply connector(s) | Solder pin(s) (SMT) Through hole solder pin(s) (2.00mm) |
IO-connector(s) | Solder pin(s) (SMT) Through hole solder pin(s) (2.00mm) |
LoRa antenna connector | Solder pin (SMT) Through hole solder pin |
Package contents | |
Package contents | 1x LoRa Module |
