JCW402 2.4GHz Antenna - RP-SMA

JCW402 2.4GHz Antenna - RP-SMA
JCW402 2.4GHz Antenna - RP-SMA
JCW402 2.4GHz Antenna - RP-SMA
JCW402 2.4GHz Antenna - RP-SMA
JCW402 2.4GHz Antenna - RP-SMA
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 006681
€2.00
Ex Tax: €1.65

An antenna from JC Antenna.

Check the tab "Downloads" for more information and/or downloads.

Please login or register to review

Reviews Over JCW402 2.4GHz Antenna - RP-SMA

This product has 0 review(s) in total.

Datasheet: 006681_JCW402.pdf

Specifications

General
Brand JC Antenna
Manufacturer model/SKU JCW402-RP-SMA
Norm conformity RoHS
Minimum operating temperature [°C] -40
Maximum operating temperature [°C] 85
General physical appearance
Main color Black
Weight [g] 10
Dimension X [mm] 10
Dimension Y [mm] 10
Dimension Z [mm] 109
Mounting options Screw thread
Form factor Individual component
Connectors
Connector type(s) RP-SMA male
Orientation Adjustable
Antenna
Frequency band(s) 2.4GHz (e.g. Wi-Fi, Bluetooth, Zigbee)
Maximum gain [dBi] 3
Impedance [Ω] 50
Radiation direction Omnidirectional
Package contents
Package contents 1x Antenna
