Name: Fischl.de USBtin EB - USB to CAN interface - FISCHL-USBTIN-EB
SKU: 005027
Price: 37.5 EUR
Availability: InStock

Fischl.de USBtin EB - USB to CAN interface

Availability: Directly available from warehouse in Eindhoven
SKU: 005027

Based on 0 review(s) - Write a review

€37.50

Ex Tax: €30.99

10 or more €37.00

20 or more €36.75

Qty

Add to Cart

Add to wishlist

20+ pieces in stock

USBtin is an open source USB to CAN interface for monitoring and transmitting CAN messages. It's easy to use and has a virtual comport on your computer that can be controlled with simple commands.

See the following page for more information: Manufacturer page

Check the tab "Downloads" for more information and/or downloads.

Please login or register to review

Reviews Over Fischl.de USBtin EB - USB to CAN interface

Average Rating:

This product has 0 review(s) in total.

Datasheet: 005027_USBtin_EB_v2.pdf

Tags: Fischl.de USBtin EB - USB to CAN interface , FISCHL-USBTIN-EB , CAN Bus

Specifications

General
Brand	Fischl.de
Manufacturer model/SKU	USBtin EB
Model revision	V2.1
Minimum operating temperature [°C]	-20
Maximum operating temperature [°C]	70
General physical appearance
Main color	Green
Weight [g]	7
Dimension X [mm]	57
Dimension Y [mm]	25
Mounting options	Mounting hole(s)
Diameter mounting hole(s) [mm]	3.2
Form factor	Module (general)
General electrical properties
Minimum supply voltage [V DC]	5
Maximum supply voltage [V DC]	5
Communication
Hardware interface(s)	USB CDC CAN
Isolated communication	No
CAN bus tranceiver	MCP2551
Number of CAN bus channels	1
Connectors
Power supply connector(s)	Mini USB female
IO-connector(s)	Mini USB female Through hole solder pin(s)
Pin distance [mm]	3.81
Package contents
Package contents	1x USBtin EB
