Removable Screw Terminal - 4p - 3.81mm

Removable Screw Terminal - 4p - 3.81mm
Removable Screw Terminal - 4p - 3.81mm
Removable Screw Terminal - 4p - 3.81mm
Removable Screw Terminal - 4p - 3.81mm
Removable Screw Terminal - 4p - 3.81mm
Removable Screw Terminal - 4p - 3.81mm
Removable Screw Terminal - 4p - 3.81mm
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 004184
€0.65
Ex Tax: €0.54

A removable screw terminal that can be easily inserted and removed from a terminal block.

Please login or register to review

Reviews Over Removable Screw Terminal - 4p - 3.81mm

This product has 0 review(s) in total.

Specifications

General
Brand No brand
General physical appearance
Main color Green
Weight [g] 3
Dimension X [mm] 16
Dimension Y [mm] 16
Dimension Z [mm] 11
Form factor Individual component
General electrical properties
Maximum voltage [V AC] 250
Maximum voltage [V DC] 250
Maximum current [A] 8
Connectors
Connector type(s) Screw terminal
Detachable block female (15EDG-3.81)
Number of conductors/pins 4
Orientation Straight
Locking mechanism Screw
Clamp
Connector system Wire-to-board
Pin distance [mm] 3.81
Package contents
Package contents 1x Screw terminal block connector
