40 Pins Header Male - 90 Degrees - Type B

40 Pins Header Male - 90 Degrees - Type B
40 Pins Header Male - 90 Degrees - Type B
  • Availability: Directly available from warehouse in Eindhoven
  • SKU: 006358
Based on 0 review(s) - Write a review
€0.50
Ex Tax: €0.41
Add to Cart
Add to wishlist

Standard male pin header which is suitable for female headers or female DuPont cables. The header is breakable which makes it easy to shorten. In this version (type B) the plastic part is on the long side of the pins, in type A the plastic is on the short side.

Please login or register to review

Reviews Over 40 Pins Header Male - 90 Degrees - Type B

This product has 0 review(s) in total.

Tags: 40 Pins Header Male - 90 Degrees - Type B , 40PMALEHAAKS , Male

Specifications

General
Brand No brand
General physical appearance
Main color Black
Weight [g] 3
Dimension X [mm] 2.5
Dimension Y [mm] 2.5
Dimension Z [mm] 102
Mounting options THT
Form factor Individual component
Experiment PCB friendly Yes
Connectors
Connector type(s) Pin header male (2.54mm)
Solder pin(s) (THT)
Number of conductors/pins 40
Number of pin rows 1
Orientation Right-angled
Locking mechanism None
Pin shape Square
Connector/pin width [mm] 0.65
Pin distance [mm] 2.54
Pin length (PCB/short side) [mm] 3
Pin length [mm] 6
Package contents
Package contents 1x Pinheader male 40p right-angled
