  • Availabilty: Directly available from warehouse in Eindhoven
  • SKU: 004824
Based on 0 review(s) - Write a review
€9.50
Ex Tax: €7.85
Add to Cart
Add to wishlist

This 1.3-inch Waveshare display HAT can be controlled via an SPI interface. The HAT has 2 integrated push buttons.

Note: No Raspberry Pi Pico is included.

See the following page for more information about this product: Waveshare 1.3 inch SPI OLED Display 128*64 pixels - for Raspberry Pi Pico

Please login or register to review
Tags: Waveshare 1.3 inch SPI OLED Display 128*64 pixels - for Raspberry Pi Pico , WS-19376 , OLED

Specifications

General
Brand Waveshare
Manufacturer model/SKU 19376
Features Display
Programmable button(s)
General physical appearance
Main color Blue
Weight [g] 11
Dimension X [mm] 52
Dimension Y [mm] 25
Mounting options Pin headers
Form factor Module (general)
Raspberry Pi Pico layout/shield
General electrical properties
Minimum supply voltage [V DC] 3.3
Maximum supply voltage [V DC] 3.3
Minimum IO-pin input voltage [V] 3.3
Maximum IO-pin input voltage [V] 3.3
IO-pin output voltage [V] 3.3
Communication
Hardware interface(s) SPI
Display
Type OLED
Driver SH1107
Screen diagonal [inch] 1.3
Number of pixels long side 128
Number of pixels short side 64
Display shape Rectangular
Pixel colors White
Switch
Switching method Manual (sensor switch)
Switch type Push
Number of channels/gangs 2
Connectors
Power supply connector(s) Pin header female (2.54mm)
IO-connector(s) Pin header female (2.54mm)
Package contents
Package contents 1x Display module
